Protection Function
Over Current Protection
Once checking current is more than 180A and lasts 3 seconds, ESC will shut off power output, and will
resume normal after making throttle zero.
Short Circuit Protection
Once checking instant current is more than 240A, ESC will power off, and will rework after trouble shooting
and powering again.
Stalling Protection
Motor stall will trigger stalling protection. ESC will resume after making throttle zero and powering again.
Voltage Protection
Once checking voltage is less than 16V or more than 64V, ESC will alarm and will not start up motor. But it
will be out of effect during flying.
Temperature Protection
When checking temperature is higher than 110 centigrade degree, ESC will output error signal. Once
temperature exceeding 140 centigrade degree, ESC will shut off and will resume normal after making throttle zero.
Throttle Loss Protection
As checking throttle signal loss over 0.3 seconds, ESC will shut off and will rework after throttle signal
recovery.
Start Protection
When motor is not started up after adding throttle for 10 seconds, ESC will shut off and will resume normal
after making throttle zero.
Throttle Stroke Setting
First connect motor and adjust throttle top, then power on and ESC will beep two times. Second adjust
throttle bottom and ESC will beep one time. After finishing these steps, throttle stroke will be set successful
DEDICATED TO MAKING GOOD MOTOR
MAD Components – innovative company, designing, developing and manufacturing brushless motor for wide range of multirotor aerial vehicles (FPVs, UAVs, quadcotpers, drones, etc.).
Nowadays, more and more manufacturers engaged in the motor production, within fierce competition, only to follow the market and make good product can gain customers’ acknowledge. No fancy words, we are dedicated to making good brushless motor for multirotors, this is what we are doing and our principle.
Our R & D team from Europe and China with proper mechanical technical manufacture and metallurgical knowledge, know how to design good motor according to customers’ demands and expectations. And with our rich production experience of brushless motor, MAD aim to offer customers tailor-made as well as co-developed power solutions for wide range of multirotors, including commercial, scientific, recreational, agricultural, and other applications, i.e.: policing, peacekeeping, and surveillance, product deliveries, aerial photography, paraglider, skateboard and drone racing.
Experience, motivation and perfect engineering stay behind reliability and effectiveness of brushless motor that MAD offer.
