Good News

Dear Customer, Now the 4 channel Hybrid DVR has Upgrade in this Month!

1. 4 Channel Hybrid DVR for Analog mode: Original: D1 real-time recording; Now change to: 960H real-time recording;

2. 4 Channel Hybrid DVR for AHD Mode: Original: AHDL Non real-time; Now change to: AHDM real-time

3. 4 Channel Hybrid DVR fo5r Network Mode: Original: 720P/1080P Real-time, Support Onvif; Now only support XM IP Camera <P2P: www.xmeye.net>, don’t support Onvif IP Camera)

4. 4 Channel Hybrid DVR: Original: BNC,VGA,HDMI Three Output; Now change to: VGA,HDMI Two Output.Please note that before you buying.

5. 4 Channel Model: Original:SAE3000-1004E, Now change to:SAE3000-A1004NS

6. Now the 8 Channel Hybrid DVR not any changed!

Resolution:
AHD-L: AHD-L Horizontal Resolution(TVL) is higher than the traditional analog 960H,equivalent to the network HD 720P

The 4 Channel Hybrid DVR Support:720P AHD Camera,Analog Camera (960H Real-time ),IP Camera(720P/1080P)

The 8 Channel Hybrid DVR Support:720P AHD Camera (Non Real-time ),Analog Camera D1 Real time (960H Non Real-time ),IP Camera(720P/1080P)

DVR/HVR/NVR features 3 in 1

For 4CH Hybrid DVR

Only analog(AHDL DVR):4ch AHDM(960H) or 4ch D1 real-time

Analog(DVR)+IP(NVR): 2*960H(Analog)+1*720P(Network)+1*960H(Network)

Only IP(NVR): 4*1080P(Network);8*D1(Network);1*1080P(Network)

For 8CH Hybrid DVR

Only analog(AHDL DVR):8*AHD-L(960H)(12 Frame); 8*D1

Analog(DVR)+IP(NVR): 2 *D1(analog)+(1*1080P(network)+ 1*720P(network)

Only IP(NVR): 8*1080P(Network); 8*720P(Network); 4*1080P((Network); 4*720P((Network); 1*1080P(Network)

1.Display:Support VGA HDMI HD output;

2.Compression algorithm ideal:H.264 High Profile compression algorithm,30% decrease of stream due to advanced space-time filtering technology.

3.Supports Motion Detection and Email Notification

4.Mobile monitor: Support various mobile monitoring(iPhone, Windows Mobile, BlackBerry, Symbian, Android).

5.Browsers:Support IE.Chrome.Firefox.Safari browsers.

6.Multi-language OSD (27 kinds of languagess):(English, Finnish, French, German, Greek, Italian, Japanese, Polish,Portuguese,Russian,Spanish,Thai,SimChinese,TradChinese,Turkish,Farsi,Hungarian,Vietnamese,Romanian,korean,Brazilian,Indonesian,Swedish,Arabic,Bulgarian,Czech,Hebrew)

7.Perfect circuit protection, unique triple watchdog function.

8.Support 2 USB2.0 interface, to achieve USB mouse, backup, burn, upgrades and other operations stably.

9.Network:Powerful network services (support DHCP, PPPOE, FTP, DNS, DDNS, EMAIL,IP searches etc.) And perfect support (WEB, Client, SDK), easy to achieve interoperability.

10.Support web client, standalone client

11.Support P2P cloud(xmeye.net), no need to do router mapping, just 1 step go to internet with P2P cloud technology

12.Playback quality: Supports full real-time encoding video, full real-time playback of multi-channel synchronous decoding.

13.Main and Sub Stream:Main stream and Sub-stream encoding. Main stream for local storage, ensure image quality; Sub-stream for real-time network transmission, easy to solve bandwidth bottleneck problem.

14.Support Onvif in Network Mode

Note :

This DVR Support the 3.5” HDD ,below picture is for reference ,Not include HDD in the box !

When you are searching for standalone digital video recorder, you will see QCIF, CIF, D1, 960H parameters in every standalone DVR technical information table. CIF, D1, 960H are the recording and playback resolution for security DVR. These parameters are very important factors determined your video recording surveillance performance and resolution.

What’s CIF ?

CIF is the abbreviation of Common Intermediate Format. CIF=360x240pixels

CIF format with follow features:

1. The resolution is suitable for video home system (VHS), with resolution 360x240pixels

2. Adopted non-interlaced scan

3. Using NTSC, play video maximum frame rate at 30 000/100129.97fps/second

4. PAL tv system, resolution reach up to 288 tv lines.

5. CIF format is an old standard for video surveillance system

What is D1 ?

In cctv system industry, everybody knows D1 is the resoltuion of recording, playback and display resolution. Actaully it’s not ture. D1 is a digital tv system standard format, it is divided into the following categories:

D1: 480i format (525i): 720×480 (resolution 480tv lines, Interlaced), and NTSC tv system with same resolution, Line frequency 15.25kHz, the equivalent of what we call 4CIF (720 × 576).

D2: 480P format (525p), 720×480 (resolution 480tv, progressive scan), with more clear compared to the D1 interlaced, is e the equivalent of DVD resolution.

D3: 1080i format (1125i): 1920×1080 (resolution 1080 tv lines, interlaced scan), high definition video format, resolution 1920x1080i/60Hz, Line frequency 33.75kHz.

D4: 720P format (750p), 1280×720 (horizontal resolution 720 tv lines, progressive scan), a low resolution compared to D3, but with reason of progressive scan, many people feel D3 is more clear than D4, especially when display the characters, resolution 1280x720p/60Hz, line frequency 45kHz.

D5: 1080P format (1125P), 1920×1080 (horizontal resolution 1080tv lines, progressive scan), the highest standard resolution in tv system, resolution 1920x1080P/60Hz, line frequency 67.5KHz.

This is mini DVR for “4 ChannelType “and “8 ChannelType” ,Now 4 Channel has upgrade,for Analog mode maximum support 960H real time, but the 8 Channel not changed, only support D1 real time, and you can set the 8ch in 960h, but 960H is non real-time, Please note this before you shopping. If you need full 960H real-time recording DVR, please contact us freely, we will recommend you another model.

This DVR Support ONVIF protocol, It’s can compatible with our own brand of the network video products, but also compatible with other brand of the network video products for Onvif, It can implement multiple devices connected to each other, mutual communication.

PC & Smartphone Remote View

Anytime, Anywhere…Using the latest network technology, plug and play, you can remote view via smart phones, tablets, notebook or PC.

Smartphone Surveillance

Support all kinds of Mobile phone monitoring(iPhone, Windows, Mobile, BlackBerry, Symbian, Android), But support P2P function only (Android, iPhone).

Advanced Motion Detection Recording

The motion detection recording function: when motion is detected the DVR will save the footage into hard disk without missing any important events.
You can even ensure that false alarms are avoided by setting the motion detection “mask†to block areas with constant movement.

E-mail Alerts

DVR will send you mail automatically if there is any motion detected.
